OptionsMag Lift ML-01
- Magnet lifting unit
- Mag Lift unit price
- ¥490,000
- Ideal for automating magnetic bead assays.
- Magnetic ON/OFF can be controlled from the software.
- Compatible with various magnets of SBS standard size, such as ALPAQUA🄬 magnetic bead separation magnet plates.
Key Specifications
| External dimensions | W95mmxD178mmxH75mm |
|---|---|
| Weight | About 1kg (excluding AC adapter) |
| Up-down stroke | 30mm (set in 0.1mm increments) |
| Power supply voltage | AC100V |
| Communication connection | USB |
| Applicable plates | SBS standard size PCR plates and microplates |
| Applicable magnetic units | SBS standard size magnetic units(height 26mm or less, weight 1.0kg or less) |
Target device
-
- EDR-384GXHigh Throughput Workstation
-
- Number of stages：12st
- Head：96/384ch
- Dispensing range：0.1-1200µL
- Price： From ￥10,800,000
-
- EDR-384SX12-Stage Workstation
-
- Number of stages： 12 st
- Head： 96/384/1536 ch
- Dispensing range： 0.1 – 300 µL
- Price： From ￥6,200,000
-
- EDR-384SX-66-Stage Workstation
-
- Number of stages： 6 st
- Head： 96/384/1536 ch
- Dispensing range： 0.1 – 300 µL
- Price： From ￥5,200,000
-
- ADS-384-24Multi-stage dispensing station for 1536/384/96 well plates
-
- Number of stages：24st
- Head：96/384ch
- Dispensing range：0.1 – 300µL
- Price： From ￥28,000,000
-
- EDR-24LXCompact Workstation
-
- Number of stages： 4 st
- Head： 1/6/12(8)/24(16) ch
- Dispensing range： 0.5 – 1000 µL
- Price： From ￥2,850,000
-
- EDR-8LZCompact 8ch variable pitch sampling system
-
- Number of stages：8st
- Head：8ch(Variable pitch)
- Dispensing range：1 -1100µL
- Price： From ￥5,300,000
-
- EDR-VS8C8ch variable pitch sampling system
-
- Number of stages： 15st
- Head： 8ch (Variable pitch)
- Dispensing range： 10-1100µL
- Price： From ￥8,800,000
-
- EDR-VS8C double range head model8ch variable pitch sampling system
-
- Number of stages： 15st
- Head： 8ch (Variable pitch)
- Dispensing range： 1-1100µL
- Price： From ￥10,300,000
-
- EDR-VS8/VS10Multichannel Variable Pitch Sampling System
-
- Number of stages： 24 st
- Head： 8/10 ch (Variable pitch)
- Dispensing range： 10 – 1100 µL
- Price： From ￥8,400,000
